| REGO 12V 400AH LITHIUM IRON PHOSPHATE BATTERY | |||
|---|---|---|---|
| Electrical Specifications | Temperature Parameters | ||
| Battery Type: Lithium Iron Phosphate | Rated Capacity: 400Ah | Standard Operation Temperature | Recommended: 59~86 ℉ / 15～30℃ |
| Nominal Voltage | 12.8 V | Storage Temperature | Less Than 1 Week: -22°F~140°F (-30°C~60°C) Less Than 6 Months: -4°F~113°F (-20°C~45°C) |
| Voltage Range | 10-14.8V | Charge Temperature | 32~131℉ / 0～55℃ |
| Cycle Life(0.5C/1C, 25℃) | 3800 Cycles at 80% DOD | Discharge Temperature | -4~131℉ / -20～55℃ |
| Charging Parameters | Mechanical Specifications | ||
| Charge Voltage | 14.4 V | Dimension (L x W x H) | 18.0 x 13.0 x 10.5 inch (457 x 329 x 267.2 mm) |
| Maximum Continuous Charge Current | 300A | Weight | 112.4 lbs. (51 kg) |
| Discharging Parameters | Protection Ratee | IP65 | |
| Maximum Continuous Discharging Current | 350A | Housing Material | Die Cast Aluminum/Extruded Aluminum |
| Discharge Cut-off Voltage | 10V | ||
| Certifications | Warranty | ||
| MSDS, UN38.3, FCC | YES | 5-year material Warranty | |
| COMMUNICATION | ACCESSORIES | ||
| Built-in Bluetooth | YES | Bolts | NO |
| Communication Port | NO | Activation Switch | NO |
Rego batteries come with an Anderson cable. And the connector is Gray Anderson 350 connector (with dust cover).
The battery is shipped in shelf mode. The battery can be activated by pressing and holding the battery button for 1 second, and the battery can be put into shelf mode by pressing and holding the battery button for 3 seconds.
Our battery is capable of 3800 cycles of perfect charge and discharge. If you live a completely off-grid life, calculated at the rate of a full charge and discharge per day, you will be able to use it for more than 10 years.
No, you can't. All the batteries you connect together should be the same capacity (Ah), the same voltage (V), and most importantly, the same battery type (LFP). And it would be better if they come from the same brand.
No, you can't. These Renogy lithium batteries do NOT support connecting in series. They are made ONLY for connecting in parallel (Up to 8P) using identical batteries with the same type (lithium), same capacity (Ah), same voltage (V), and same brand (Renogy).
The Rego battery has built-in Bluetooth and also has CAN communication ports. It supports both Bluetooth communication and CAN (RV-C) communication.
The battery has a built-in heater. When the battery temperature drops below 41°F (5°C), and the charge current is stable and greater than 15A, the heater starts operating automatically, and the Heater Status Indicator lights up green.
This Rego battery has a self-heating function. The operating temperature for discharging is -4°F to 140°F / -20°C to 60°C. The operating temperature range for charging is -4°F to 122°F / -20°C to 50°C.
Yes, this battery is compatible with Renogy ONE M1 & Core.
 |
 |
