Easier & Faster in Just One Go
Core - 12V 200Ah Lithium Iron Phosphate Battery
Long Terminal Bolts
2 x M8 x 1.25 x 20 mm
|Renogy 12V 200Ah Core Series Deep Cycle Lithium Iron Phosphate Battery|
|Electrical Specifications||Temperature Parameters|
|Rated Capacity (0.5C, 25°C)||200 Ah||Operation Temperature Range||Charge: 32°F to 131°F / 0°C to 55°C|
|Nominal Voltage||12.8 V||Operation Temperature Range||Discharge: -4°F to 140°F / -20°C to 60°C|
|Energy||2560Wh||Storage Temperature Range||-13°F to 149°F / -25°C to 65°C|
|Cycle Life(0.5C/1C, 25℃)||5000 Cycles (80% DOD 80% EOL)||Operation Relative Humidity||10% to 95%|
|Charging Parameters||Mechanical Specifications|
|Charge Voltage||14.4 V||Dimension (L x W x H)||20.55 x 9.45 x 8.62 in / 522 x 240 x 219 mm|
|Maximum Continuous Charge Current||100 A||Weight||47.3 lbs. / 21.45 kg|
|Discharging Parameters||Terminal Bolt Size||M8 x 1.25 x 15 mm|
|Maximum Continuous Discharge Current||200A||Protection Rating||IP65|
|Peak Discharge Current||400A@10s|
|MSDS, UN38.3, FCC, PSE, CE, UKCA||YES||5-year material Warranty|
Yes. Renogy 12V Core Series Batteries can be connected in series to ramp up voltage for a 24V, 36V, or 48V off-grid power system. You can also consider wiring batteries in series first and then wire sets of batteries (same models required) in parallel for maximum power up to 40.96kWh.
The Core Series batteries support versatile connections, including series, parallel, and series-parallel connection. You can connect up to 4 batteries in series, 8 in parallel, or 16 in the series-parallel connection. Batteries of the same model and similar capacity are required.
No. This battery is not compatible with the Bluetooth module. You can use a 500A Battery Monitor With Shunt (sold separately) to keep track of battery status.
Whether you prefer charging batteries via solar, a DC-DC battery charger, or an AC-DC charger, we highly recommend a solar charge controller/charger that is compatible with lithium iron phosphate batteries.
